Name: BioAffix CardReader Desktop
Brand: BioAffix

Height: 88 mm

Width: 56 mm

Thickness 19 mm

125 kHz:

134.2 kHz:

13.56 MHz:

F Type	125 kHz, 134,2 kHz AWID, Cardax, CASI-RUSCO, Deister, EM4100, 4102, 4200, EM4050, 4150, 4450, 4550, EM4305, FDX-B, EM4105, HITAG 1, HITAG 2, HITAG S, ICT, IDTECK, Isonas, Keri, Miro, Nedap, Pyramid, Q5, T5557, T5567, T5577, TITAN (EM4050), UNIQUE
	13,56 MHz ISO14443A: LEGIC Advant, MIFARE Classic, MIFARE Classic EV1, MIFARE Mini, MIFARE DESFire EV1, MIFARE DESFire EV2, MIFARE Plus S, X, MIFARE Pro X, MIFARE Ultralight, MIFARE Ultralight C, MIFARE Ultralight EV1, NTAG2xx, SLE44R35, SLE66Rxx (my-dmove), Topaz ISO14443B: Calypso, Calypso Innovatron protocol, CEPAS, HID iCLASS, Moneo, Pico Pass, SRI4K, SRIX4K, SRI512, SRT512 ISO15693: EM4x33, EM4x35, HID iCLASS, HID iCLASS SE/SR, ICODE SLI, LEGIC Advant, M24LR16/64, MB89R118/119, SRF55Vxx (my-d vicinity), Tag-it, PicoPass
P Type	F Type + Cotag, G-Prox*, HID DuoProx II, HID ISO Prox II, HID Micro Prox, HID ProxKey III, HID Prox, HID Prox II, Indala, ioProx, Nexwatch
PI Type	F Type + P Type + HID iCLASS, HID iCLASS SE/SR/Elite, HID iCLASS SEOS(CSN & Facility Code/PAC)

Reading Distance: Up to 10 cm

MTBF: 500.000 hours

Connection: USB 2.0

Audio Warning:

Led:

Scroll the table

Model	Açıklama
DON-BIO-CAR-DES-F	BioAffix CardReader Desktop-LF+HF Desktop Card Reader F
DON-BIO-CAR-DES-F-BLE	BioAffix CardReader Desktop-LF+HF Desktop Card Reader F + BLE
DON-BIO-CAR-DES-P	BioAffix CardReader Desktop-LF+HF Desktop Card Reader P
DON-BIO-CAR-DES-PI	BioAffix CardReader Desktop-LF+HF Desktop Card Reader PI
DON-BIO-CAR-DES-SMA-F	BioAffix CardReader Desktop-LF+HF Desktop Touchless + Contact Card Reader F
